Product description
Ultrasonic metal wire harness welder is a crucial welding technology for wire harnesses for various industries. This machine adopts Pneumatic motion control system, which is convenient to operate, fast, and efficient. The key parts of the ultrasonic wire harness welder has strong power and good stability. The ultrasonic wire harness welding machine has the function of preventing false welding, which can effectively prevent damage to the welding sonotrode. The welding power of this machine can be monitored in real-time during welding, which can effectively guarantee the yield rate. KM-HMS-X00N series ultrasonic wire harness welder can provide you with efficient welding methods and reduced production cost.
The ultrasonic wire welding machine can be used for welding non-ferrous materials such as aluminum, copper, silver, chrome-nickel, and other conductive metals, and can be widely used for welding wires of electrical automobiles, electronic motors and other electrical equipment, etc.
Ultrasonic metal welding is the use of the amount of tens of thousands of times per second high-frequency vibration wave transmission to the surface of the two metal work pieces to be welded, and then a certain pressure is applied, thus the metal surface friction and the formation of molecular layers can achieve the purpose of welding.
♦ DIGITAL CONTROL
♦ 7-inch Color Touch Screen
Fully digitally controlled, and touch screen display is intuitive for operation. The ultrasonic power supply has the unique functions as follows to guarantee the welding yield rate.
1. Ultrasonic sweeping and detecting;
2. Supporting a variety of welding modes;
3. Preventing false weld and mistake welding;
4. Storing parameter/welding data.
♦ COMPACT STRUCTURE
♦Integrated Motion Control System
The ultrasonic wire harness welding machine adopts pneumatic plus stepping motor motion system, thus fast welding speed (less than 10s) and high efficiency can be guaranteed. Compact and integrated design can meet your needs for working in flexible environment.
Product parameters
|
Model |
KM-HMS-X00N |
|
Ultrasonic freq. |
20kHz |
|
Ultrasonic output power (Max.) |
2000W |
|
Welding scope |
0.35-12mm² (wire bundle section area) |
|
Single wire size in OD |
≤0.3mm |
|
Weld mode |
Time |
|
Power source voltage |
110/220VAC,50/60Hz |
|
Display screen |
7 inches Touch Screen |
|
Motion control |
Pneumatic |
|
Air source |
>0.5mpa, filtered dry air |
|
Productivity |
About 0.6s/pcs, based on the wires |
|
Net weight |
38KG |
|
Dimension(mm*mm*mm) |
Welding Stack: 570*220*175 mm /Power controller:385*350*165mm |
Welding case
Company Advantages
· KnMTech ultrasonic welding system is manufactured under the guidance of our experienced professionals, using advanced machines and tools in tandem with international quality standards.
· After years of exploration and practice, a perfect quality control system is established to ensure the product quality.
· The product has stand in a reputable position in the market.
Company Features
· Occupying an irreplaceable position in China market, K&M Technologies Ltd. experienced in developing and manufacturing high-quality ultrasonic welding system.
· We have implemented a quality management system in the plant. The system requires daily routine measurement records for every production stage, so as to guarantee high-quality output.
· Our experts welcome the opportunity to meet your unique ultrasonic welding system design requirements while conforming to the quality and production standards of the industry. Call now!
Application of the Product
K&M Technologies Ltd.'s ultrasonic welding system is widely applicable in the industry.
K&M Technologies Ltd. has many years of industry experience and strong production strength. According to different needs of customers, we are able to provide customers with excellent and efficient one-stop solutions.
